36W DIN rail power supply 24V/1.5A

Name: HDR-30-24 - MEAN WELL - 36W DIN rail power supply 24V/1.5A
Brand: MEAN WELL
SKU: HDR-30-24
Price: 12.20 CHF
Availability: InStock

CHF 12.20 excl. VAT, plus shipping costs

Item no: HDR-30-24

Stock level:196 Available immediately

Packaging ex works: 96 piece

5+ ~~CHF 12.20~~ CHF 11.60 (4%save)

10+ ~~CHF 11.60~~ CHF 11.10 (9%save)

20+ ~~CHF 11.10~~ CHF 10.80 (11%save)

Recommend:

Delivery time request Print PDF

Description

HDR-30-24 is an ultra-compact DIN rail power supply for installation in distribution boards. Approved for industrial and domestic applications, the power supplies are the ideal solution for industrial control systems and building automation.

Technical data

No load power consumption 0.3W
Suitable for mounting on TS-35/7.5/15 top-hat rails
Haushaltszulassung EN61558-2-16
Protection class II Device without earth connection
Dimensions 35 x 90x 54.5mm (W x H x D)

Additional information

DIN rail power supplies

Output voltage (Vdc)	24
Power (W)	36
Output current (A)	1.5
Input voltage range (Vac)	85 to 264
Connection	Screw terminal
Certificates	EN61558-1, EN61558-2-16, IEC62368-1, UL508, UL62368-1, EAC TP TC 004, CNS15598-1, OVC III, LPS
Overload behavior	Hiccup mode
Product series	HDR
Width (mm)	35
Height (mm)	90
Depth (mm)	54.5
Manufacturer	MEAN WELL

LEDs

Manufacturer's warranty	3 years
Efficiency typ.	89%

Data sheets

Data sheet HDR-30	PDF(889.4 KB)
Test Report HDR-30-24	PDF(175.53 KB)
Installation Manual HDR	PDF(841.53 KB)
Carbon Footprint declaration HDR-30	PDF(73.8 KB)

Downloads

3D data HDR-30	Zip file (1.24 MB)
