100W DIN rail power supply 24V/4.2A

Name: HDR-100-24N - MEAN WELL - 100W DIN rail power supply 24V/4.2A
Brand: MEAN WELL
SKU: HDR-100-24N
Price: 23.70 CHF
Availability: InStock

CHF 23.70 excl. VAT, plus shipping costs

Item no: HDR-100-24N

In stock: Available to order

Packaging ex works: 48 piece

Estimated delivery time: 2 weeks

5+ ~~CHF 23.70~~ CHF 22.60 (4%save)

10+ ~~CHF 22.60~~ CHF 21.60 (8%save)

20+ ~~CHF 21.60~~ CHF 21.00 (11%save)

Recommend:

Delivery time request Print PDF

Description

HDR-100-24N is an ultra-compact DIN rail power supply for installation in distribution boards. Approved for industrial and domestic applications, the power supplies are the ideal solution for industrial control systems and building automation.

Technical data

Suitable for mounting on TS-35/7.5/15 top-hat rails
Haushaltszulassung EN61558-2-16
Protection class II Device without earth connection
Dimensions 70 x 90 x 54.5mm (W x H x D)

Additional information

DIN rail power supplies

Output voltage (Vdc)	24
Power (W)	100
Output current (A)	4.2
Input voltage range (Vac)	85 to 264
Connection	Screw terminal
Certificates	EN61558-1, EN61558-2-16, IEC62368-1, UL508, UL62368-1, EAC TP TC 004, CNS15598-1, OVC III
Overload behavior	Hiccup mode
Product series	HDR
Width (mm)	70
Height (mm)	90
Depth (mm)	54.5
Manufacturer	MEAN WELL

LEDs

Manufacturer's warranty	3 years
Efficiency typ.	90%

Data sheets

Data sheet HDR-100	PDF(1.38 MB)
Installation Manual HDR	PDF(841.53 KB)
Carbon Footprint declaration HDR-100	PDF(73.78 KB)

Downloads

3D data HDR-100	Zip file (471.26 KB)
