30W DIN rail power supply 12V/2.5A
CHF 15.20 excl. VAT, plus shipping costs
Description
With an output power of 30 watts, this power supply is the entry-level model in the series of 2U (36 mm) wide REFIN AC/DC power supplies in a modular design for DIN rails, which are intended for low-profile distribution cabinets
such as those typically used in building automation. Simple electrical connections for single- or multi-conductor wires can be made using spring-loaded plug-in terminals—without the need for wire end ferrules or tools. Thanks to the mounting tabs on the rear, the modules can also be installed in any orientation on a mounting plate, even without a DIN rail. Any installation position, as well as side-by-side mounting of multiple modules, is supported.
Technical data
- 85–305 VAC wide-range input
- 2 U width (36 mm); 151 g weight
- 30 watts from -40°F to 132°F
- Can be mounted in any orientation. Also without a DIN rail
- Acoustic noise cancellation
- LPS; NEC Class 2
Additional information
| DIN rail power supplies | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||
| Maintenance aids | ||||||||||||||||||||||||
|
|
||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||
|
|
||||||||||||||||||||||||
| More | ||||||||||||||||||||||||
|
||||||||||||||||||||||||
Data sheets
| REFIN2U-S30L Data Sheet | PDF(1.14 MB) |
|---|---|
| REFIN2U-S30 Installation Instructions | PDF(1.53 MB) |
