DIN rail power supplies
96W UPS power supply unit with battery charging function for 12V battery
CHF 46.40 excl. VAT, plus shipping costs
Item no:
DRC-100A
Stock:5 Available immediately
Packaging ex works:
30 piece
5+ CHF 46.40 CHF 44.20 (4%save)
10+ CHF 44.20 CHF 42.20 (9%save)
20+ CHF 42.20 CHF 41.00 (11%save)
Description
DRC-100A is a 100W DIN rail power supply unit with UPS function. In addition to the main output, the power supply unit has a charging output for connecting a backup battery.
Technical data
- Suitable for mounting on TS-35/7.5/15 top-hat rails
- Output voltage adjustable with internal potentiometer
- With battery charging function for UPS operation
- Alarm signal for AC OK and battery low via relay contact
- Operating temperature range from -30°C to +70°C
- LED display for DC OK
- Dimensions 55 x 90 x 100mm (W x H x D)
Additional information
| DIN rail power supplies | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||
|
|
||||||||||||||||||||||||
| UPS & Security | ||||||||||||||||||||||||
|
||||||||||||||||||||||||
| More | ||||||||||||||||||||||||
|
||||||||||||||||||||||||
Data sheets
| Data sheet DRC-100 | PDF(253.57 KB) |
|---|---|
| Test Report DRC-100A | PDF(347.84 KB) |
| Carbon Footprint declaration DRC-100 | PDF(73.88 KB) |
Downloads
| 3D data DRC-100 | Zip file (754.92 KB) |
|---|
