Current transformer
Fluxgate current transformer 25A / DC, AC, pulse / low drift / multi-range (primary conductor with 2×2 windings, differential measurement)
Compact fluxgate current transformer, unipolar supply (+5 V), special version: primary conductor is designed as a double conductor with 2 windings each and intended for differential measurement
Item no:
CASR 25-NP/SP1
In stock: Available to order
Please register for price display.
Description
- Special version: The primary conductor is designed as a double conductor with 2 windings each and is intended for differential measurement
- Low offset and gain drift
- Measuring range of up to 3 x IPN
- Printed circuit board assembly
- 5 year guarantee
- Compact design (30% lower overall height than LTS)
- High accuracy at +85°C
Technical data
- Measurement of DC, AC and pulse currents with galvanic isolation
- Unipolar supply voltage +5Vdc
- Test voltage: up to 4.3kVrms / 50Hz / 1min
- Fluxgate technology
- Voltage output
- DC bandwidth up to 300kHz (+/-3dB), 200kHz (+/-1dB)
- Fast response time 0.3µs
- Access to the reference voltage via an additional pin
Additional information
| Current transformer | ||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||
|
||||||||||||||||||||||||||
Data sheets
| CASR 25-NP/SP1 | PDF(1.21 MB) |
|---|
Downloads
| 3D Step File CASR 25-NP | Zip file (1.01 MB) |
|---|
