1000W Power Supply 12V/83.4A, Industrial, Medical, Household

CHF 210.40 excl. VAT, plus shipping costs

Item No.: NSP-1000-12
In stock: Available to order
Packaging ex works: 9 piece
5+ CHF 210.40 CHF 200.50 (4%save)
10+ CHF 200.50 CHF 191.60 (8%save)
20+ CHF 191.60 CHF 186.00 (11%save)
Wish listWish list
Wish list
Questions
Delivery time request  Print PDF

Description

The NSP-1000 series delivers 1000 W of power in a compact enclosure and features programmable output voltage and current, 200% peak power, CAN bus communication, and parallel operation up to 4000 W. Thanks to 2xMOPP isolation, a wide temperature range, and extensive certifications, it is suitable for industrial, medical, and home automation applications.

Technical data

  • Input voltage 85 to 305Vac
  • With active PFC
  • Metal housing with screw terminals
  • 2,000 watts of peak power for 5 seconds
  • Protective lacquered PCB
  • CAN bus interface
  • Can be connected in parallel up to 4000 W (3+1)
  • Suitable for BF applications
  • Operating temperature range from -40°C to +85°C
  • Dimensions 230 x 127 x 41mm (L x W x H)

Additional information

Enclosed power supplies
Output voltage (Vdc)

12

Power (W)

1000

Input voltage range (Vac)

85 to 305

Protection class

Class I

Application

Household, ITE/AV, Medical

Further functions

Protective coating, 5 Vdc auxiliary output, 12 Vdc auxiliary output, OVC III, parallel-connectable, peak power

Control

Analog, CAN bus

Status signals

DC OK signal

Control signals

Programmable current, Programmable voltage, Remote ON/OFF, Remote Sense

Manufacturer

MEAN WELL

Length (mm)

230

Width (mm)

127

Height (mm)

41
Maintenance aids
LEDs
More
Voltage setting range (Vdc)

0 to 14.4Vdc

Efficiency typ.

92%

Manufacturer's warranty

5 years

Baseplate cooling power (W)

1000

Convection power (W)

1000

Data sheets

NSP-1000 Data Sheet PDF(1.89 MB)
NSP-1000 User Manual PDF(7.18 MB)

Downloads

3D STEP File NSP-1000 Zip file (801.41 KB)
