960W DIN rail power supply 48V/20A, peak power
CHF 213.50 excl. VAT, plus shipping costs
Description
XDR-960 is an ultra-slim, high-end 960-watt DIN rail power supply. With a width of only 96 mm, it saves a lot of space in the control cabinet. The high efficiency of up to 96% and the low standby power consumption of <1.5 watts save energy and reduce waste heat.
To short-term peak currents To cover the connected consumers, the power supply briefly delivers up to 200% of the nominal current. In addition, a O-ring FET from regenerative power supply of motors or inductive loads. A built-in Inrush current limiter enables multiple network devices to be started up simultaneously without tripping the fuse.
The integrated MODBus interface enables monitoring and control of the power supply unit and facilitates integration into the overall system.
Comprehensive protection circuits, worldwide safety approvals, and a 5-year manufacturer's warranty make the XDR-960 the ideal power supply for compact and reliable applications.
Variant with screw terminal connection
Technical data
- Worldwide certifications for various areas of application
- Protected against short circuit, overload, overvoltage and overtemperature
- Temperature range from -40° to +85°C (derating from 60°C)
- Operating altitude up to 5000 M (OVCIII up to 2000M)
- Inrush current <10A
- MODBus interface
Additional information
