DC/DC DIN rail mounting
480W DC/DC converter, input 16.8...33.6V, output 24V/20A
CHF 173.00 excl. VAT, plus shipping costs
Item no:
DDR-480B-24
In stock: Available to order
Packaging ex works:
8 piece
Estimated delivery time:
1 to 2 weeks
5+ CHF 173.00 CHF 164.80 (4%save)
10+ CHF 164.80 CHF 157.50 (8%save)
20+ CHF 157.50 CHF 153.00 (11%save)
Description
DDR-480B-24 is a DC-DC converter for industrial or railroad applications. The compact converter for DIN rail mounting can be loaded up to 150% for short periods. Up to 4 converters can be operated in parallel to increase the power.
Technical data
- 2:1 Entrance area
- 4000Vdc insulation
- Convection-cooled without forced ventilation
- 150% peak load for 5 seconds
- DC OK relay contact
- Remote ON/OFF
- Parallel switchable up to 1920W (3+1)
- Overload circuit with constant current limiting
- Complies with railroad approval EN50155 and EN45545-2
- Operating temperature range from -40°C to +80°C
- Dimensions 85.5 x 125.2 x 128.5mm (L x W x H)
- 3-year guarantee
Additional information
| DC-DC converter | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||
|
|
||||||||||||||||||||||||
| More | ||||||||||||||||||||||||
|
||||||||||||||||||||||||
Data sheets
| Data sheet DDR-480 | PDF(440.98 KB) |
|---|---|
| Test Report DDR-480B-24 | PDF(374.52 KB) |
| Installation Manual DDR | PDF(924.02 KB) |
| Carbon Footprint declaration DDR-480 | PDF(74.03 KB) |
Downloads
| 3D data DDR-480 | Zip file (5.3 MB) |
|---|
