LED dimmer
5 channel DMX512 RDM LED dimmer, RGBWW, constant voltage 12-36VDC, max. 900W
CHF 102.40 excl. VAT, plus shipping costs
Item no:
SR-2108-V600-RGBWW-CV
Stock level:59 Available immediately
Description
SR-2108-V600-RGBWW-CV with RDM function, adjustable PWM resolution/frequency and DMX512 interface is ideal for the operation of RGBW constant voltage LED applications such as LED strips.
Control
- DMX512 RDM
Application
- RGBW, RGB, Tunable White, Single Color
Dimming range
The load-independent dimming range is 0.1% to 100% of the connected load.
Technical data
- DMX512 RDM 5 channel dimmer
- The RDM function enables communication between the master and decoder
- Standard DMX512-compliant control interface, allows the DMX address to be set freely and shows the address on a digital numerical display.
- PWM frequency adjustable between 500Hz and 30kHz
- Compatible with standard DMX systems
- Digital DMX address display
- Gamma value of the dimming curve adjustable between 0.1-9.9
- IP20 Degree of protection
- Plastic housing
- Operating temperature range from -20°C to +50°C
- Dimension 170 x 59 x 29mm
- 5 year guarantee
Additional information
| LED dimmer | ||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||
Data sheets
| SR-2108-V600-RGBWW-CV | PDF(550.42 KB) |
|---|
