Current transformer
Current transformer 50A / measuring range 150A / small design / high interference immunity / DC, AC, and pulse currents
The LEM HAIS 50-TP is a compact Hall effect current sensor for precise measurement of DC and AC currents up to ±150 A. With ratiometric voltage output, high accuracy, and fast response time, it is ideal for industrial applications such as frequency converters, motor controls, and power supplies. Thanks to galvanic isolation and a 5 V supply, it can be easily integrated into electronic systems.
CHF 30.60 excl. VAT, plus shipping costs
Item no.:
HAIS 50-TP
Stock level:100 Available immediately
Description
- Series: HAIS
- Closed loop Hall effect current sensor (AC, DC, pulse current measurement)
- Galvanic isolation of primary and secondary circuit
- Bandwidth: DC up to 50 kHz
- Housing: UL 94-V0 plastic
- Assembly: PCB
- 5 year guarantee
- Advantages: Small design, high noise immunity
- Typical applications: Drives, frequency converters, battery-powered applications UPS, SMPS, welding applications
Technical data
- Rated current: 50 A
- Measuring range: up to 150 A
- Voltage output, direct imaging, ratiometric: +2.5V+/-0.025V
- Supply: +5V unipolar
- Accuracy: ±1 %
- Operating temperature: -40 °C to +85 °C
Additional information
| Current transformer | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||
|
||||||||||||||||||||||||
Data sheets
| HAIS 50-TP | PDF(665.04 KB) |
|---|
Downloads
| 3D STEP file HAIS 50-TP | Zip file (540.71 KB) |
|---|
