Current transformer
Current transformer 500A / TRUE-RMS / split core / DC, AC currents up to 6kHz
Compact and versatile current transformers for high AC and DC currents.
CHF 300.10 excl. VAT, plus shipping costs
Item no:
AHR 500 B10
In stock: Available to order
Description
- Current transformer and signal conditioning in one housing
- Foldable (split core)
- Complete range of AC and DC current measurements
- Effective RMS (True RMS)
- Output 0-10V (B10)
- 1% absolute accuracy
- Bandwidth: DC 20..6000Hz
- Manufacturer LEM
Technical data
- Supply range 20 to 50Vdc
- Operating temperature -40°C to +70°C
- Isolated test voltage 5kVrms / 50Hz / 1min
- Conductor bushing 104 x 40mm (for non-contact measurement)
- Foldable (split core version)
- Dimension 174 x 86 x 54.1 mm
- Use of UL94-V0 recognized materials
Additional information
| Current transformer | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||
|
||||||||||||||||||||||||
Data sheets
| AHR 500 B10 | PDF(203.14 KB) |
|---|---|
| 3D CAD Model AHR Series | PDF(60.05 KB) |
Downloads
| 3D Step File AHR 500 B10 | Zip file (273.68 KB) |
|---|
