US400 Ultrasonic Cleaner

Name: US400 Ultrasonic Cleaner
Brand: Reeco
SKU: SI20970001
Price: 2775.00 CHF
Availability: InStock

CHF 2'775.00 excl. VAT, plus shipping costs

Item no: SI20970001

In stock: Available to order

Estimated delivery time: 3-4 weeks

Recommend:

Delivery time request Print PDF

Description

The US400 is a high-performance, digitally controlled ultrasonic cleaner designed for industrial applications involving large workpieces and demanding cleaning requirements. The system is engineered for continuous operation in production facilities, workshops, and laboratories, and enables efficient, consistent, and gentle cleaning.

Properties

Digitally controlled ultrasonic cleaning
Adjustable cleaning time from 1 to 99 minutes
Real-time display of ultrasound power and fluid temperature
Temperature control from 0 °C to 80 °C
Automatic overheating protection with interruption of the cleaning process
Audible signal before and after the cleaning cycle
High-performance ultrasonic system for large components
Integrated drainage system for cleaning fluid
Rugged industrial design for multi-shift operation
ESD-safe, grounded metal construction

Areas of application

The US400 is designed for demanding industrial cleaning processes:

Cleaning of large printed circuit boards and electronic assemblies
Medical and surgical instruments
Dental Technology and Prosthodontics
Jewelry and Watch Industry
Optical Components and Precision Systems
Weapons and machinery components
Mechanical components such as bearings, carburetors, and fuel injection systems
Laboratory and analytical instruments
The Printing Industry and Photopolymer Cleaning
General industrial fine and precision cleaning

Advantages

Exceptionally high cleaning performance for large workpieces
Sturdy steel construction designed for continuous industrial use
Maintenance-friendly modular design
Low operating costs relative to performance
Efficient ultrasonic transmission via bolted modules
User-friendly controls
Tank design reduces splashing and vapor production
Designed for 16/24-hour multi-shift operation

Technical data

Supply voltage: 230 V / 50 Hz
Ultrasonic power: 1200 W
Heat output: 2000 W
Tank capacity: max. 60 L / optimal 50 L
Internal dimensions of the tank: 610 × 500 × 200 mm
Unit dimensions: 680 × 560 × 350 mm
Temperature range: 0 °F to 80 °F
Time setting: 1–99 minutes

Scope of delivery

US400 Ultrasonic Cleaner
lid
Fluid pump

Optional accessories

Stainless steel basket
Also available in a version with two separate cleaning tanks

Technical Specifications US400-2

Model with two separate tanks.

Feature	Value
Supply voltage	230 V / 50 Hz
Ultrasonic power	1200 W
Heating capacity	2000 W
Fuel capacity	2 × 26 L / ideally 2 × 22 L
Internal dimensions of the tank	500 × 300 × 200 mm per tank
Device dimensions	680 × 560 × 350 mm
