150W AC/DC power supply 24V/6.25A

Name: RAC150-24SG/ENC - Recom - 150W AC/DC power supply 24V/6.25A
Brand: Recom
SKU: RAC150-24SG/ENC
Price: 63.00 CHF
Availability: InStock

CHF 63.00 excl. VAT, plus shipping costs

Item no: RAC150-24SG/ENC

In stock: Available to order

10+ ~~CHF 63.00~~ CHF 59.30 (5%save)

25+ ~~CHF 59.30~~ CHF 55.20 (12%save)

50+ ~~CHF 55.20~~ CHF 53.05 (15%save)

Recommend:

Delivery time request Print PDF

Description

The RAC150 series are cost-effective 150 watt AC/DC power supplies in a standard 2″x4″ format with a universal input range of 90-264VAC for worldwide use. They deliver up to 125 watts with natural air convection for use in tight, space-critical enclosures with low airflow. The UL and CE marks with CB reports include both the new 62368 safety standard and the previously used 60950 safety standard. The RAC150 series offers tightly regulated 12V, 24V and 48VDC outputs with 3kVAC isolation and Class B EMC certifications and comes with a three-year warranty.

Technical data

Universal input 90-264VAC
Efficiency 91 %
Protection against short circuit and overvoltage
Active PFC function, PF>0,95
Power indicator LED
UL, CE-marked (CB report)
Protective coating standard

Additional information

Enclosed power supplies

Output voltage (Vdc)	24
Power (W)	150
Input voltage range (Vac)	90 to 264
Protection class	Class I
Application	ITE/AV
Manufacturer	Recom
Length (mm)	105
Width (mm)	62
Height (mm)	35

LEDs

Manufacturer's warranty	3 years
Efficiency typ.	91%

Data sheets

Data sheet RAC150-G	PDF(292.92 KB)
Installation Guide RAC150-G_ENC	PDF(137.84 KB)

Downloads

3D Step File RAC150-G_ENC	Zip file (886.16 KB)
