320W Power supply 24V/13.4A, Industrial, Medical, Household
CHF 41.80 excl. VAT, plus shipping costs
Description
The NSP-320 is a powerful 320 watt power supply unit with integrated PFC function. It meets the highest reliability requirements and is certified for use in ITE/AV, medical and household applications. Thanks to its compact design, outstanding efficiency and a wide temperature range of -40 °C to +85 °C, it can be used in a wide variety of applications. With the peak power function, twice the power can be supplied at short notice.
Technical data
- Input voltage 85 to 305Vac
- With active PFC
- Peak power of 640W for 5 seconds
- Metal housing with screw terminals
- Protective lacquered PCB
- Operating temperature range from -40°C to +85°C
- Dimensions 179 x 99 x 30mm (L x W x H)
Additional information
| Enclosed power supplies | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||
|
|
||||||||||||||||||||||||
| More | ||||||||||||||||||||||||
|
||||||||||||||||||||||||
Data sheets
| Data sheet NSP-320 | PDF(1.07 MB) |
|---|---|
| DVT Test Report NSP-320-24 | PDF(978.77 KB) |
| Carbon Footprint Declaration NSP-320 | PDF(73.53 KB) |
Downloads
| 3D Step File NSP-320 | Zip file (805.95 KB) |
|---|
