300W Power supply 5V/60A

Name: HRPG-300-5 - MEAN WELL - 300W Power supply 5V/60A
Brand: MEAN WELL
SKU: HRPG-300-5
Price: 73.60 CHF
Availability: InStock

CHF 73.60 excl. VAT, plus shipping costs

Item no: HRPG-300-5

In stock: Available to order

Packaging ex works: 15 piece

5+ ~~CHF 73.60~~ CHF 70.10 (4%save)

10+ ~~CHF 70.10~~ CHF 67.00 (8%save)

20+ ~~CHF 67.00~~ CHF 65.10 (11%save)

Recommend:

Delivery time request Print PDF

Description

HRPG-300-5 is a robust switching power supply with integrated fan for applications with high demands on service life and reliability with stand-by function

Technical data

Input voltage 85 to 264Vac
With active PFC
Remote On/Off
Standby 5V@0.3A
Remote Sense function
Power consumption at no load <0.5W
Air cooling with integrated fan
Operating temperature range from -40°C to +70°C
Withstands surge voltages up to 300Vac for up to 5 seconds
Dimensions 199 x 105 x 41mm (L x W x H)

Additional information

Enclosed power supplies

Output voltage (Vdc)	5
Power (W)	300
Input voltage range (Vac)	85 to 264
Protection class	Class I
Setting range Vdc max	5.8
Setting range Vdc min	4.3
Application	ITE/AV
Further functions	5Vdc auxiliary output
Status signals	DC OK signal
Control signals	Remote ON/OFF, Remote Sense
Manufacturer	MEAN WELL
Length (mm)	199
Width (mm)	105
Height (mm)	41

LEDs

Manufacturer's warranty	5 years
Efficiency typ.	82%

Data sheets

Data sheet HRPG-300	PDF(633.45 KB)
Test Report	PDF(160.53 KB)
Installation Manual Enclosed	PDF(995.59 KB)
Carbon Footprint declaration HRPG-300	PDF(73.92 KB)

Downloads

3D data HRPG-300	Zip file (259.96 KB)
