PCB mount power supplies
40W medical AC/DC power supply unit, PCB mounting, 5V/8A
CHF 19.20 excl. VAT, plus shipping costs
Item no:
MPM-45-5
In stock: Available to order
Packaging ex works:
60 piece
5+ CHF 19.20 CHF 18.30 (4%save)
10+ CHF 18.30 CHF 17.50 (8%save)
20+ CHF 17.50 CHF 17.00 (11%save)
Description
MPM-45-5 is an ultra-compact AC-DC power supply with medical approval for PCB mounting in an encapsulated housing.
Technical data
- Input voltage 80 to 264Vac
- Peak power 110% of the nominal power for 10 seconds
- No load power consumption 0.1W
- Very low leakage current (100µA)
- Protection class II Device without earth connection
- Wide temperature range from -30 to +80°C
- 2x MOPP (insulation: primary to secondary)
- Suitable for BF applications
- Operating altitude up to 4000 meters
- Short-circuit, overload, overvoltage and overtemperature protection
- Medical approval according to ANSI/AAMI ES60601-1 and IEC/EN60601-1
- Dimensions 87 x 52 x 29.5mm (L x W x H)
Additional information
| Power supply units for PCB mounting | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||
| LEDs | ||||||||||||||||||
|
|
||||||||||||||||||
| More | ||||||||||||||||||
|
||||||||||||||||||
Data sheets
| Data sheet MPM-45 | PDF(262.74 KB) |
|---|---|
| Test Report MPM-45-5 | PDF(414.64 KB) |
| Installation instructions PCB power supply units | PDF(830.11 KB) |
Downloads
| 3D data MPM-45 | Zip file (559.58 KB) |
|---|
