DC/DC PCB assembly
2W DC/DC converter, input 21.6...26.4V, output 12V/0.167A
CHF 3.80 excl. VAT, plus shipping costs
Item no:
SPUN02N-12
In stock: Available to order
5+ CHF 3.80 CHF 3.60 (5%save)
10+ CHF 3.60 CHF 3.50 (7%save)
20+ CHF 3.50 CHF 3.40 (10%save)
Description
2W DC/DC converter, input 21.6...26.4V, output 12V/0.167A
Technical data
- SIP7 housing with industry standard pinout
- Operating temperature range -40°...+105°C
- Complies with EN55032 radiated class B without additional components
- Efficiency 87
- Protective circuit: short circuit/overcurrent
- 3kVdc I/O isolation
- Low cost
- 3-year guarantee
- Manufacturer Mean Well
Additional information
| DC-DC converter | ||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||
|
||||||||||||||||||||||||||
Data sheets
| Data sheet SPUN02 | PDF(119.52 KB) |
|---|
Downloads
| 3D data SPUN02 | Zip file (167.13 KB) |
|---|
