DC/DC PCB assembly
14.8W DC/DC converter, input 9–75 V, output 3.3 V/4.5 A
CHF 29.40 excl. VAT, plus shipping costs
Item No.:
SKMW20W8-03
In stock: Available to order
5+ CHF 29.40 CHF 28.20 (4%save)
10+ CHF 28.20 CHF 27.80 (5%save)
20+ CHF 27.80 CHF 25.30 (13%save)
Description
The SKMW20W8 are isolated 20W DC-DC converters housed in a 1×1-inch package. With an 8:1 input range, these converters support a wide range of input voltages, making them suitable for use in a variety of applications.
Technical data
- DIP housing 1''x1'' with industry standard pinout
- 8:1 ultra-wide input voltage range
- High efficiency of up to 88%
- Temperature range: -40° to +90°C
- No minimum load required
- Complies with EN55032 radiated class A without additional components
- Protective circuit : Permanent short circuit/overcurrent/overvoltage/undervoltage cut-off
- 1.5kVdc I/O isolation
- 3-year guarantee
- Manufacturer Mean Well
Additional information
| DC-DC converter | ||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||||||
| Maintenance aids | ||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||
Data sheets
| SKMW20W8 Data Sheet | PDF(282.22 KB) |
|---|---|
| DVT Test Report SKMW20W8-03 | PDF(319.6 KB) |
Downloads
| 3D STEP File SKMW20W8 | Zip file (44.45 KB) |
|---|
