DC/DC PCB assembly
60W DC/DC brick converter Input 14…160V, Output 54V/1.111A
CHF 70.90 excl. VAT, plus shipping costs
Item no.:
RQB60W12-110S54
In stock: Available to order
Packaging ex works:
11 pieces per bar / 132 pieces per carton
5+ CHF 70.90 CHF 67.40 (4%save)
10+ CHF 67.40 CHF 64.50 (9%save)
20+ CHF 64.50 CHF 62.80 (11%save)
Description
RQB60W12 is a 60W DC-DC converter in a quarter brick housing. With a very wide input range of 14 to 160Vdc, the railway converter is suitable for a wide variety of input voltage ranges.
Technical data
- Quarter brick housing
- Complies with railroad standard EN50155
- 12:1 Entrance area
- Remote On/Off
- No minimum load required
- Protective circuit: overtemperature/overvoltage/overcurrent/short circuit (continuous)
- Trim range output voltage +/- 10%
Additional information
| DC-DC converter | ||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||
Data sheets
| Data sheet RQB60W12 | PDF(341.97 KB) |
|---|---|
| DVT Test Report RQB60W12-110S54 | PDF(255.24 KB) |
Downloads
| 3D data RQB60W12 | Zip file (123.59 KB) |
|---|
Accessories
-
RQB150W12-110S54
150W DC/DC brick converter Input 14...160V, output 54V/2.778ACHF 121.60Available to order -
RQB40W12-110S54
