DC/DC PCB assembly
6W medical DC/DC converter, input 4.5...9V, output 5V/1.2A
CHF 42.90 excl. VAT, plus shipping costs
Item no:
MOP06-05S05A
In stock: Available to order
Description
6W medical DC/DC converter, input 4.5...9V, output 5V/1.2A
Technical data
- Wide input voltage range 2:1/4:1
- IEC/EN60601-1 (2 x MOOP) approved
- Reinforced insulation voltage 3kVac
- Low no-load current consumption
- Deep leakage current
- Protective circuit: overcurrent / overvoltage / short circuit / undervoltage
- EMI EN55032 class A
- 5 year guarantee
- Manufacturer P-Duke
Additional information
| DC-DC converter | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||
Data sheets
| Data sheet MOP06-W | PDF(478.56 KB) |
|---|---|
| Characteristic curves MOP06 | PDF(1.76 MB) |
Downloads
| 3D data MOP06 | Zip file (76.62 KB) |
|---|
