DC/DC PCB assembly
20W DC/DC converter, input 43…160V, output +/-12V / +/-0.833A
CHF 44.40 excl. VAT, plus shipping costs
Item no:
EC7BW-110D12
In stock: Available to order
Description
20W DC/DC converter, input 43…160V, output +/-12V / +/-0.833A
Technical data
- 20Watt isolated output
- Efficiency 90
- Fixed switching frequency
- 18:1 Input voltage ratio
- Regulated outputs
- Remote ON/OFF
- Deeper No load power consumption
- Protective circuits: Overcurrent/overvoltage/short circuit/overtemperature/undervoltage
- 2''x1''x0.4'', corresponds to industry standard
- CB Test Certificate IEC62368-1
- Fire & smoke complies with EN45545-2
- Shock & Vibration complies with EN50155 (EN61373)
- UL62368-1 2nd Reinforced Insulation approval
- Operational use 5000m.a.s.l.
- 2-year guarantee
- Manufacturer Cincon
Additional information
| DC-DC converter | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||
Data sheets
| Data sheet EC7BW | PDF(147.38 KB) |
|---|---|
| Application note EC7BW | PDF(1.03 MB) |
Downloads
| 3D data EC7BW | Zip file (205.55 KB) |
|---|
