DC/DC PCB assembly
10W DC/DC converter, input 18…75V, output +/-12V / +/-0.416A
CHF 22.40 excl. VAT, plus shipping costs
Item no:
EC2SBW-48D12
In stock: Available to order
Description
10W DC/DC converter, input 18…75V, output +/-12V / +/-0.416A
Technical data
- 10W isolated outputs
- Shielded metal housing
- Efficiency 86
- 4:1 Entrance area
- Regulated outputs
- Protective circuit: Input undervoltage/short circuit
- Remote On/Off
- Safety standard UL60950-1, EN60950-1 and IEC60950-1
- Dimensions 25.4 x 25.4 x 10.2mm (L x W x H)
- 2-year guarantee
- Manufacturer Cincon
Additional information
| DC-DC converter | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||
Data sheets
| Data sheet EC2SBW | PDF(171.08 KB) |
|---|---|
| Application note EC2SBW | PDF(1.29 MB) |
Downloads
| 3D data EC2SBW | Zip file (44.76 KB) |
|---|
