DC/DC PCB assembly
75W DC/DC converter, input 9...75V, output 48V/1.56A
CHF 126.20 excl. VAT, plus shipping costs
Item no:
CQB75W8-36S48
In stock: Available to order
Description
75W DC/DC converter, input 9...75V, output 48V/1.56A
Technical data
- Efficiency 90
- Fixed switching frequency
- Regulated outputs
- Remote ON/OFF
- Deeper No load power consumption
- Protective circuit: overcurrent/overvoltage/overtemperature/undervoltage cut-off
- 3000Vac I/O isolation
- Housing temperature -40°...+105°C
- Quarter brick according to industry standard 2.28 "x1.45 "x0.5"
- CB Test Certificate IEC62368-1
- UL62368-1 2nd, Reinforce Insulation
- EN50155 compliant with external components
- Shock & Vibration EN50155 (EN61373) compliant
- Fire & Smoke EN45545-2 compliant
- 5000m operating altitude
- 2-year guarantee
- Manufacturer Cincon
Additional information
| DC-DC converter | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||
Data sheets
| Data sheet CQB75W8 | PDF(405.91 KB) |
|---|---|
| Application note CQB75W8 | PDF(1.5 MB) |
Downloads
| 3D data CQB75W8 | Zip file (590.12 KB) |
|---|
