600W DC/DC converter, input 43...160V, output 48V/12.5A
CHF 352.80 excl. VAT, plus shipping costs
Description
The CFB600W-110S series is an industry standard DC-DC converter with up to 600 W output power. It has a wide input voltage range from 43 to 160VDC (110VDC nominal) with 2250Vdc isolation.
Thanks to the high efficiency of up to 88%, operation in the
temperature range from -40°C to 100°C is possible. A very low power consumption in idle mode (25mA) makes the converter the ideal solution for energy-critical system applications.
Technical data
- 600W isolated outputs
- Efficiency up to 88%
- Regulated outputs
- Protective circuit: overtemperature/overvoltage/overcurrent/permanent short circuit
- Isolated remote on/off control
- Full Brick industry standard
- UL60950-1 2nd (Basic Insulation)
- Complies with EN50155 with external components
- Shock & Vibration complies with EN50155(EN61373) and Fire & Smoke complies with EN45545-2
- 2-year guarantee
- Manufacturer Cincon
Additional information
| DC-DC converter | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||
Data sheets
| Data sheet CFB600W | PDF(149.48 KB) |
|---|---|
| Application note CFB600W-110 | PDF(1.61 MB) |
Downloads
| 3D data CFB600W-110 | Zip file (762.39 KB) |
|---|
