DC/DC DIN rail mounting
240W DC/DC converter, input 16.8...33.6V, output 24V/10A
CHF 82.60 excl. VAT, plus shipping costs
Item no:
DDR-240B-24
In stock: Available to order
Packaging ex works:
20 piece
Estimated delivery time:
1 to 2 weeks
5+ CHF 82.60 CHF 78.70 (4%save)
10+ CHF 78.70 CHF 75.20 (8%save)
20+ CHF 75.20 CHF 73.00 (11%save)
Description
DDR-240B-24 is a 240W DC-DC converter for the DIN rail for industrial and railroad control, security, communication systems and other areas.
Possible applications are DC step-down/step-up regulators, increasing the insulation level of the system and voltage drop compensation in the line.
Technical data
- Conforms to EN50155 and EN45545-2
- Width only 40mm
- 2:1 wide input voltage range
- -40°..+70°C wide temperature range
- 150% peak load
- Parallel switchable to 960W (3+1)
- Adjustable output voltage
- Convection cooling
- For DIN Rail TS-35/7.5 or 15
- Protective circuits: Short circuit/overcurrent/overvoltage/overtemperature range/input polarity reversal/input undervoltage
- 4KVdc I/O Reinforced Isolation
- DC OK Relay contact
- Remote ON/OFF control
- 3-year guarantee
- Manufacturer Mean Well
Additional information
| DC-DC converter | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||
|
|
||||||||||||||||||||||||
| More | ||||||||||||||||||||||||
|
||||||||||||||||||||||||
Data sheets
| Data sheet DDR-240 | PDF(270.03 KB) |
|---|---|
| Test Report DDR-240B-24 | PDF(363.66 KB) |
| Installation Manual DDR | PDF(924.02 KB) |
| Carbon Footprint declaration DDR-240 | PDF(74.01 KB) |
Downloads
| 3D data DDR-240 | Zip file (545.77 KB) |
|---|
