LED converter constant voltage
30W DALI/Push+Triac+0/1-10V, 24Vdc constant voltage LED driver
CHF 52.20 excl. VAT, plus shipping costs
Item no:
SRP-2305-30-MULTIDIM-24V
Stock level:55 Available immediately
Description
SRP-2305-30-MULTIDIM-24V is a flexible, dimmable LED converter with 24V constant voltage output. This 4in1 power supply unit can be controlled with DALI, TRIAC, AC-Push etc.
Control
- DALI, AC-PUSH, 0/1-10V, TRIAC
Application
- Single Color
Dimming range
The load-independent dimming range is 1% to 100%.
Dimming method: PWM
Technical data
- DALI DT6 dimmable 1-channel single color power supply unit
- 220-240VAC wide input voltage range
- 1-channel 24V constant voltage output
- The maximum output power is 30W
- Built-in DALI 2 interface, DALI DT6 device
- Generally compatible with DALI masters that support DT6 commands
- High power factor and efficiency
- IP20 Protection class
- Protection class II Driver without earth connection
- Plastic housing
- Operating temperature range from -20°C to +45°C
- Dimension 170 x 53 x 28mm
- 5 year guarantee
Additional information
| LED constant voltage | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||
Data sheets
| SRP-2305-30-MULTIDIM-24V | PDF(266.15 KB) |
|---|
