LED dimmer
3 channel RF LED dimmer, RGB, constant voltage 12-36VDC, max. 324W
CHF 66.00 excl. VAT, plus shipping costs
Item no:
SR-1009-216-RGB-CV
In stock: Available to order
Description
SR-1009-216-RGB-CV with PWM output and RF wireless interface is ideal for the operation of RGB constant voltage LED applications such as LED strips.
Control
- RF Wireless (radio)
Application
- RGB, Tunable White, Single Color
Dimming range
The load-independent dimming range is 0.1% to 100% of the connected load.
Technical data
- RF Wireless 3 CHANNEL DIMMER
- Can be used as RGB, TW or single color control unit
- Max. Output current: 3A per channel
- Max. Output power at 24VDC: 216W
- With built-in repeater function for high performance
- Compatible with all remote controls in the SC-1009 series
- IP20 Degree of protection
- Plastic housing
- Operating temperature range from -20°C to +40°C
- Dimension 160 x 30 x 19mm
- 5 year guarantee
Additional information
| LED dimmer | ||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||
Data sheets
| SR-1009-216-RGB-CV | PDF(200.1 KB) |
|---|
Accessories
-
SC-1009-RGBW-W4
RF remote control, RGBW, color wheel, blackCHF 73.709 Available immediately -
SC-1009-RGBW-B
RF remote control, RGBW, blackCHF 28.4018 Available immediately -
CABLE1M-RGB-AWG20
RGB cable AWG20, SRGB (roll = 200m)CHF 208.4011 Available immediately -
SF15-F140-RGB
Flexible RGB LED strip / 22W / RGB / 15m8 Available immediately
