M16 crimp insert (w) 8-pin (4+3+PE) 600V without contacts
Sales price (VP) per 1 piece
CHF 7.70 excl. VAT, plus shipping costs
Item no:
7003908102
Stock level:40 Available immediately
Packaging ex works:
25 pcs
Description
Hummel socket insert - M16 signal 8-pin (4+3+PE), 600V without contacts
.
Other, not published HUMMEL products and versions on request.
Technical data
- Connection type: Crimping
- Number of poles: 8
- Pole image: 4 + 3 + PE
- Coding: PE
- Application: Socket
- Color contact insert: white
- Insulator material: PA 6, PBT
- Number of contacts Signal: 4
- Number of contacts Power: 4
- Number of contacts PE: 1
- Contact Ø signal: 0.8 mm
- Contact Ø power: 1.25 mm
- Connection cross-section power: 0.34 - 1.5mm2
- Rated current signal: 5A
- Rated current power: 16A
- Rated voltage for pollution degree 3 Signal: 160 V~
- Rated voltage for pollution degree 3 Power: 600 V~
- Test voltage signal: 1500 V~
- Test voltage power: 2500 V~
- Insulation resistance signal: > 10^8 Ω
- Insulation resistance power: > 10^8 Ω
- max. contact resistance signal: 3 mOhm
- Temperature range: -40°C...+125°C
- Degree of soiling: 3
- Flammability: V-0 (UL 94)
// Crimpeinsatz ohne Kontakte
Subject to errors and technical changes
