Adhesives
LOCTITE® HY 4090 Universal structural adhesive, 50g

LOCTITE® HY 4090 Universal structural adhesive, 50g

CHF 75.50 excl. VAT, plus shipping costs

Item no: SI1778011
Stock: Available to order
Estimated delivery time: 1 week
5+ CHF 75.50 CHF 71.50 (5%save)
Wish listWish list
Wish list
Questions
Delivery time request  Print PDF

Description

LOCTITE HY 4090 is an off-white to light yellow 2-component hybrid adhesive, high viscosity/drop-free, for structural bonding. It achieves high moisture and vibration resistance.
LOCTITE® HY 4090 is a highly viscous, off-white to light yellow, gel-like adhesive. It opens up completely new areas of application for structural bonding - for the very first time, the properties of instant adhesives are combined with those of epoxies, thus achieving further remarkable advantages. Achieves hand strength in 90 - 180 seconds and is suitable for gap sizes up to 5 mm. Resistant to vibration, impact and shock loads. Best results are achieved when used with the LOCTITE® 50 ml static mixer (IDH 1826921), LOCTITE® 400 ml static mixer (IDH 1573135) or the LOCTITE® 96001 (IDH 267452) or LOCTITE® 983439 (IDH 218311) dispensing gun.

  • Resistant to vibrations, impact and shock loads
  • Temperature resistant up to 150 °C
  • Gap filling capacity up to 5mm
  • High moisture resistance
  • UV-resistant for outdoor use

Technical data

Applications Direct bonding, edge bonding, bonding of rubber, bonding of plastics, bonding of different material combinations, construction, exterior repairs, interior repairs, structural bonding
Number of components 2K
Application method Dosing gun
Curing technique 2K mixture, curing at room temperature (ambient temperature)
Alignment time <180.0 sec.
FEA (finite element analysis) Finite elongation, viscoelastic
Gap filling 2.0 mm
Mixing ratio, weight 1 : 1
Physical form Liquid
Recommended for use with Thermoset, Elastomer: Highly filled elastomer, Epoxy, Fiberboard, Gelcoat, Wood, Rubber, Plastic, Painted surfaces, Laminate, Metal, Without gelcoat, Phenolic resin, Thermoplastic, Dry surfaces, Urethane: Urethane casting, Composite materials, Composite materials: Advanced composites, Vinyl
Shear strength, steel (sandblasted) 17.0 N/mm² (2420.0 psi )
Resin
Color, resin Crystal clear
Viscosity, cone-plate system, resin @ 25.0 °C 4000.0 - 7000.0 mPa.s (cP)
Hardener
Color, hardener Cream colored
Viscosity, cone-plate system, hardener @ 25.0 °C 25000.0 - 40000.0 mPa.s (cP)
Mixture
Operating temperature, mixture -40.0 - 300.0 °C (-40.0 - 284.0 °F )
Color, mixture Cream colored
Main properties, mixture Curing speed: Fast curing, Moisture-resistant, Moisture-resistant, Impact-resistant, Gap-filling, UV-resistant, Vibration-resistant, Viscosity: High viscosity

Additional information

Adhesives
Product

Structural adhesive

Suitable application

Rubber, plastic, metal

Temperature range Application

-40 °C to +150 °C

Viscosity class

High

Viscosity in mPa-s

4000 -7000

Dripping time / processing time

2 minutes

Content Quantity

50g

Color

Transparent

Container

Cartridge

Manufacturer

LOCTITE
LEDs
More
Container size (g)

50

Data sheets

TDS PDF(81.53 KB)
