Enclosed power supplies
3216W Power supply 48V/67A
CHF 507.00 excl. VAT, plus shipping costs
Item no:
NSP-3200-48
Stock: Available to order
Packaging ex works:
4 piece
Estimated delivery time:
1-2 weeks
5+ CHF 507.00 CHF 483.00 (4%save)
10+ CHF 483.00 CHF 461.60 (8%save)
20+ CHF 461.60 CHF 448.30 (11%save)
Description
NPU-3200-48 is a 3.2kW power supply unit with a 1U profile, a very high power density and an excellent price-performance ratio.
Technical data
- Input voltage 90 to 264Vac (derating at input <180Vac)
- with active PFC
- Very high efficiency up to 94.5%
- Remote Sense and Remote On/Off functions integrated
- Auxiliary circuit 12V/0.8A
- Output voltage can be trimmed between 50 - 125% using an external control signal
- Alarm signal outputs (TTL open collector signal): DC OK, temperature alarm
- Operating temperature range from -30°C to +70°C (derating from +50°C)
- Dimensions 325.8 x 107 x 41mm (L x W x H)
Additional information
| Enclosed power supplies | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||
Data sheets
| Data sheet NSP-3200 | PDF(453.95 KB) |
|---|---|
| Test Report NSP-3200-48 | PDF(586.98 KB) |
| Installation Manual Enclosed | PDF(995.01 KB) |
| Carbon Footprint declaration NSP-3200 | PDF(74.36 KB) |
Downloads
| 3D Step File NSP-3200 | Zip file (403.69 KB) |
|---|
