LED constant voltage
90W LED driver with PWM output 48V/1.88A
CHF 61.90 excl. VAT, plus shipping costs
Item no:
PWM-90-48
Stock: Available to order
Packaging ex works:
18 piece
Description
PWM-90-48 is an LED converter with PWM output and integrated 3in1 interface. The power supply unit is designed for the operation of constant voltage LED applications.
Control
- 0/1-10V signal (10V=100% brightness, 0.6V=0.15% brightness, 0V=off)
- Resistance (100kΩ=100% brightness, 6kΩ =0.15% brightness, 0kΩ=off)
- 10V PWM signal (100% duty cycle=100% brightness, 6% duty cycle=0.15% brightness, 0% duty cycle=off)
Dimming range
The load-independent dimming range is 0.15% to 100% of the connected load.
Technical data
- Can be used as a constant voltage source
- No load power consumption 0.5W
- Built-in 3in1 dimming function (0-10Vdc, PWM, resistor)
- Output voltage with PWM dimming
- IP67 design
- Protection class II Driver without earth connection
- Plastic housing
- Operating temperature range from -40°C to +70°C
- Dimensions 171 x 63 x 37.5mm (L x W x H)
Additional information
| LED constant voltage | ||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||
Data sheets
| Data sheet PWM-90 series | PDF(832.68 KB) |
|---|---|
| Test Report PWM-90-48 | PDF(172.4 KB) |
| Protection LED power supplies | PDF(29.09 KB) |
| Installation instructions Mean Well LED driver | PDF(1.2 MB) |
