120W DIN rail power supply 48V/2.5A, single phase
CHF 51.70 excl. VAT, plus shipping costs
Description
The Mean Well SDR-120-48 was developed to meet the highest demands. This DIN rail power supply offers impressive performance and reliability for your professional electronics projects. With a rated power of 120 watts and an output voltage of 48V, the SDR-120-48 is the ideal choice for industrial applications and demanding environments. In the short term, the power supply delivers up to 150% peak power.
Technical data
- Built-in active PFC
- Suitable for mounting on TS-35/7.5/15 top-hat rails
- 150% peak load
- Operating temperature range from -25°C to +70°C
- DC OK relay contact
- Dimensions 40 x 125.2 x 113.5mm (W x H x D)
Additional information
| DIN rail power supplies | ||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||
|
||||||||||||||||||||||||||
Data sheets
| Data sheet SDR-120 | PDF(644.72 KB) |
|---|---|
| Test Report SDR-120-48 | PDF(122.33 KB) |
| User Manual SDR | PDF(988.71 KB) |
| Carbon Footprint declaration SDR-120 | PDF(73.94 KB) |
Downloads
| 3D data SDR-120 | Zip file (3.94 MB) |
|---|
