DC/DC PCB assembly
20W DC/DC converter, input 9...36V, output +15V/-15V / +0.667A/-0.667A
Item no:
RCD20-24D15W
Stock: Available to order
Please register for price display.
Description
20W DC/DC converter, input 9...36V, output +15V/-15V / +0.667A/-0.667A
Technical data
- 20Watt regulated
- 4:1 Wide entrance area
- Efficiency 91
- Standard 1.00'' x 1.00'' x 0.39'' Size
- IN/OUT insulation 3000Vdc
- Input voltage ranges: 9..36Vdc, 18..75Vdc, 36..160Vdc
- Remote ON/OFF
- Protective circuit: short circuit, overcurrent, overvoltage, overtemperature and undervoltage
- Temperature range: -55°C...+100°C (M3 version)
- Built-in EMI CLASS A filter
- 3-year guarantee
- Manufacturer P-DUKE
Additional information
| DC-DC converter | ||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
||||||||||||||||||||||||||||
| LEDs | ||||||||||||||||||||||||||||
|
|
||||||||||||||||||||||||||||
| More | ||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||
Data sheets
| Data sheet RCD20W | PDF(428.31 KB) |
|---|
